Circle Cutting Machines
Sign Board Circle Cutting Machine
标志牌剪圆机
Round sign and nameplate blanks for the traffic-sign industry.
- Purpose-built for the sign board industry
- Cutting speed 30 m/min
- Diameters from Ø800 to Ø1500 mm
- 0.3–3 mm reflective-sheet capacity
Models: NY800-3 · NY1250-3 · NY1500-3
Specifications
Technical parameters
| Model | Cutting dia. (inner–outer) | Thickness | Speed | Motor | Machine size (mm) |
|---|---|---|---|---|---|
| NY800-3 | Inner Ø300 – Outer Ø800 mm | 0.3–3 mm | 30 m/min | 0.8–1.5 kW | 3200×800×2000 |
| NY1250-3 | Inner Ø300 – Outer Ø1250 mm | 0.3–3 mm | 30 m/min | 0.8–1.5 kW | 3600×1000×2000 |
| NY1500-3 | Inner Ø300 – Outer Ø1500 mm | 0.3–3 mm | 30 m/min | 0.8–1.5 kW | 4100×1000×2000 |
Voltage 380V as standard — export voltage can be configured for the destination market. Custom tooling available on request.
Applications
Where this machine works
Overview
Machine description
Sign shops need round blanks that stay flat and scratch-free — the sign board series cuts Ø800 to Ø1500 mm discs at 30 m/min with handling matched to large, thin sheets.
Three sizes share a 0.3–3 mm capacity and a tall double-column frame that supports full-size sign sheet through the cut. Compatible with the reflective sheeting used on traffic signs.
